Digital Retro-fit DR Solutions
C-DR & C-FP - Retrofit Chiropractic Solutions
Upgrade your chiropractic practice with 20/20 Imaging’s Retrofit Digital X-ray Solutions — designed to seamlessly convert your existing analog or CR system into a state-of-the-art digital radiography (DR) workflow. Whether you run a compact clinic or a high-volume office, our retrofit packages deliver fast digital imaging, efficient diagnostics, and enhanced patient care without replacing your entire X-ray unit.
Choose the DR panel configuration that best fits your workflow. The Universal-DR Wireless panel provides the freedom of cable-free operation and is available in both 17×17 and optional 14×17 sizes for added flexibility. The Universal-DR Hybrid panel combines wireless freedom with the security of a tethered connection when needed. For practices that prefer a direct link, the Universal-DR Tethered panel offers consistent wired performance with no charging required. All panels feature advanced cesium scintillator technology for crisp imaging at lower dose and include a custom-fit holder for clean integration into your X-ray setup.
Paired with Symmetry-Sync software, each retrofit system comes loaded with chiropractic-specific tools such as Orthogonal Analysis, Gonstead measurements, Penning Analysis, and long-length stitching. A user-friendly interface, customizable workflows, and secure PACS functionality ensure smooth image management from acquisition to archive.
With robust PC hardware, extended warranty options, and ongoing support, 20/20 Imaging retrofit solutions make it simple to step into digital — improving diagnostic accuracy, patient outcomes, and daily workflow without the cost and complexity of a new X-ray system.
Meet the system:
DR Panel Choices
20/20 Imaging offers cost-effective retrofit solutions that transform your existing chiropractic X-ray equipment into a fully digital system. Our retrofit packages integrate seamlessly with most analog units, allowing you to upgrade to high-resolution digital imaging without replacing your current hardware. Paired with our intuitive software platform, including image acquisition and PACS, you’ll experience streamlined workflow, enhanced image quality, and advanced chiropractic toolsets — all while preserving your existing investment. It’s the smart way to go digital.
- Fully-tethered detector
- Scintillator: Csl, 139 micron
- Always powered via direct connection
- 5-Year Warranty
Universal-DR 17x17 Tethered
- Wireless detector
- Scintillator: Csl, 139 micron, 7.9 lbs
- Optional tether for power flexibility
- 5-Year Warranty
- Also available in 14x17
Universal-DR 17x17 Wireless
Universal-DR 17x17 Tethered Panel
A direct-connect design ensures consistent performance with no charging required. The 17×17 panel features a modular cable system for easier setup and replacement, and it integrates seamlessly with chiropractic stands to deliver images within seconds of exposure.
Universal-DR 17x17 Wireless Panel
This 17×17 panel delivers high-quality digital images with the freedom of wireless connectivity. It includes two hot-swappable batteries for continuous use, along with fast transfer speeds and dependable auto-exposure detection — eliminating the need for extra cabling or fixed connections.
NEW 17x48 DR Panel
Single exposure full spine solution
- Detector Technology: Amorphous Silicon
- Scintillator: Csl (Cesium)
- Active Area: 17"x48"
- Pixel Size: 139 micron
- Spatial Resolution: 3.6 lp/mm
Our Universal-DR 17" x 48” single exposure, dose reducing, time saving full spine panel. Improving workflow efficiency while improving the patient experience.
Acquisition Interface
Superior Image Quality
- Sharper images, optimized clarity
- Configured for grid suppression
- Quick view selection
- Customizable image sharpness level
- Auto Contrast upon processing
- Image auto-shutter/crop
- Images auto-save during acquisition to Server for immediate access in exam rooms
PC Hardware
Business Class Components†
Small Form Factor All-in-One PC
- Intel Processor, 32GB RAM
- Dual 2TB NVMe (Mirrored) Storage
- Wi-Fi 6E + Dual Ethernet
24" LED IPS 2MP Touchscreen Monitor
- 10-point Touchscreen
- High Quality Display for optimized viewing
- VESA Wall-mount compatible
Symmetry-Sync Software
↑ Multi-functional Studylist
- Cybersecurity features
- Customizable Workflow & Interface
- Full PACS Functionalities included
- View from anywhere, anytime*
← Diagnostic Client DICOM Image Viewer
- User friendly & Easy to Use
- Full Clinical Toolset included
- Customizable toolbox for your favorite tools
← Zero-footprint Web DICOM Image Viewer
- Utilize any web browser
- Requires no installation, runs through browser
- Customizable tools & layouts
Included Chiropractic Tool-Set
- NEW Penning Analysis
- Advanced Orthogonal Analysis
- Gonstead measurements
- Upper Cervical Analysis
- George’s Lines
- Ilium Analysis
- Line Drawing
- Measuring
- Angles (Regular, Cobb)
- Cervical Curve
- Lumbar Curve
- Orthospinology
- Full Spine Stitching
- Spine Labeling *DC Tools-Set Included
On-Site Install & Training
- System setup by professional 20/20 certified installer
- Full training for both doctors and x-ray techs
- Monitoring by tech to ensure entire trained staff is completely comfortable
Warranty
- Momentum DR Panel: 3 year warranty (7 years Capacitor/Battery)
- FP, FPH, FPW: DR Panel: 5 year warranty
- PC Components: 3year full on-site incl. parts†††
- Experienced live technician support after installation
